Concealed thermostatic shower mixer, 3-outlet CONCEALED_ZB019200
Model
ZB019200
Concealed thermostatic shower mixer, 3-outlet,with 1/2" 2-outlet deviastop cartridge,without trim kit
Available Finishings
Technologies
Thermostatic
The Huber thermostatic is your personal water manager, helping you to handle, control and save water and energy.
Characteristic
Installation: Concealed
Cartridge Spare Parts: 24.04A.PP
Cartridge Name: 8x20 Plus P Thermostatic Valve
Concealed: 1
Waterflow
ZB019200
| Pressure | Shower(l/min) | Bath(l/min) |
|---|---|---|
| 1 Bar | 13 | 14 |
| 2 Bar | 18 | 20 |
| 3 Bar | 22 | 24 |
| 4 Bar | 26 | 28 |
| 5 Bar | 28 | 31 |
