H2
Single lever bath mixer, with shower set H2_H2000123
Model
H2000123
Single lever bath mixer, with shower set,wall mounted adjustable handshower bracket,ABS D.26 mm minimalistic one spray handshower,Brass 150 cm flexible hose
Available Finishings
Technologies
EcoStop
EcoStop feature limits water flow to approximately 50% of maximum output with one point of resistance on setting. Push slightly past the middle stop only when full water output is required. This will save water up to 50%.
Characteristic
Cartridge Spare Parts: ZZ95435000
Cartridge Name: 35 mm Cartridge
Waterflow
H2000123
| Pressure | Shower(l/min) | Bath(l/min) |
|---|---|---|
| 1 Bar | 5.5 | 11 |
| 2 Bar | 7.8 | 16.1 |
| 3 Bar | 9.4 | 19.8 |
| 4 Bar | 10.7 | 22.9 |
| 5 Bar | 11.5 | 25.8 |
