Concealed thermostatic bath mixer, 2-outlet CONCEALED_ZB019340
Model
ZB019340
Concealed thermostatic shower mixer, 2-outlet,without trim kit
Available Finishings
Technologies
Thermostatic
The Huber thermostatic is your personal water manager, helping you to handle, control and save water and energy.
Characteristic
Installation: Concealed
Cartridge Spare Parts: 24.04A.PP
Cartridge Name: 8x20 Plus P Thermostatic Valve
Concealed: 1
Waterflow
ZB019340
| Pressure | Shower(l/min) | Bath(l/min) |
|---|---|---|
| 1 Bar | 13 | 13.5 |
| 2 Bar | 18.5 | 19.7 |
| 3 Bar | 22.4 | 24.4 |
| 4 Bar | 26.7 | 28.4 |
| 5 Bar | 28.2 | 31.9 |
External Parts
External parts usable with current element
