H3
2-function Thermostatic shower set H3_H3C82010
Model
H3C82010
2-function Thermostatic shower set,2-outlet deviastop,adjustable riser column,sliding handshower bracket,100 mm ABS 3 sprays handshower,250 mm ABS round showerhead,150 cm smooth SILVERFLEX Flexible Hose
Available Finishings
Technologies
DeviaStop
The Huber Devia Stop technology allows to adjust the water flow and to direct it to the selected output point (overhead soaker, hand shower, etc).
SafeTouch
The Huber SafeTouch system maintains the mixer body cool to the touch during operation.
Thermostatic
The Huber thermostatic is your personal water manager, helping you to handle, control and save water and energy.
Characteristic
Cartridge Spare Parts: 22.04A.AR - ZZ97279004
Cartridge Name: Argo 2 (long filter) Thermostatic Valve
Waterflow
H3C82010
| Pressure | Shower(l/min) | Rain(l/min) |
|---|---|---|
| 1 Bar | 5.23 | 8.9 |
| 2 Bar | 5.80 | 13.2 |
| 3 Bar | 6.01 | 16.4 |
| 4 Bar | 6.34 | 19.2 |
| 5 Bar | 6.34 | 21.6 |
